Figure 6 NOTE: In BULK, the Charge Controller will charge as long as necessary to complete
the cycle, regardless of the timer's set points
ADVANCED MENU
Absorb End Amps
EXIT NEXT
ADVANCED MENU

Rebulk Voltage

EXIT NEXT
50
Charge Controller Multi-Stage Battery Charging
00 A
-
+
12.6 V
-
+
An Absorb charge cycle normally ends when a battery
voltage is maintained at the Absorb set point for the
user-determined time period. Use the < -> or < + > soft
keys to adjust the Absorb End Amps to an optimal value
(the default value is 00). While the battery voltage is at or
above the Absorb target and the Absorb End Amps value
is reached for a time delay of 15 seconds, the Charge
Controller will switch to the Float stage regardless of
the charger time minutes as shown in the Misc menu
under ChgT. The charger timer will be cleared. This is an
optional set point and is used for few installations.
When fi nished with any adjustments, press the <NEXT>
soft key to view the Rebulk Voltage screen.
In Float, if the battery voltage falls below the ReBulk
Voltage set point for at least 90 seconds, the Charge
Controller will automatically reinitiate a Bulk charge cycle.
The default is set to 6 volts, a very low value that will
disable this function. The Rebulk Voltage value can be
adjusted by pressing the < - > or < + > soft keys. Press
the <NEXT> soft key to view the Vbatt Calibration screen.
