6. End of Day Summary Screen

The End of Day summary screen appears after one hour of continuous sleeping. This screen can be
opened anytime by pressing the second soft key while in the STATUS screen, providing a summary up
to that point.
Day (up to 128 days)
Peak Input Voltage
Maximum batt
voltage obtained
Minimum batt
voltage obtained
NOTE:
• Pressing the fi rst soft key opens the STATUS screen.
• Pressing the second soft key brings up the CLEAR LOG screen.
• Pressing the third soft key shows the previous day's summary; continually pressing this soft key will
bring up additional past summaries up to 128 days.
• Pressing the fourth soft key will bring up summary for the 128th day back.

7. Recharging Using the PV Array

In 113.6 V
Out 12.5 V
0.000 kW
AUX: OFF
In 87.6 V
Out 12.5
0.410 kW
AUX OFF
21
Peak output current
Today 0000AH 00.0 kWH
011Vp 00.0Ap 0.00kWp
MAX 14.7 V
MIN 14.6 V FLT 00:00
0.0 A
0.0 A
0.0 kWH
Sleeping
5.0 A
V 32.9 A
0.0 kWH
MPPT Bulk
Accumulated amp hours
ABS 01:00
Turn the PV input breaker on. The Charge Controller
automatically detects the PV input voltage.
(NOTE: If PV voltage registers "000V" when the breaker is
on, please check the polarity of the PV wires.)
The Charge Controller enters a "Wakeup" stage, transitions
to "Tracking" and prepares to charge the batteries by
tracking the maximum power point of the solar array.
During the Charge Controller's initial tracking, the input
source (e.g., solar) is gradually loaded from the open
circuit voltage (VOC) to one-half of the VOC. Within this
range, the Charge Controller seeks the maximum power
point. When the Charge Controller goes into Re-Cal,
Auto Restart, Wakeup, or RSTRT (restart) modes, among
other conditions, it performs an initial tracking.
Accumulated KWh total
power production
Peak kiloWatt hours
Accumulated absorb time
Accumulated fl oat time
