Outback Power Systems FlexMax 60 User Manual page 31

Hold Time Sec
BACK -
AUX MODE
PV Trigger
EXIT
AUX MODE
PV Trigger
Output: On
EXIT NEXT SET MODE
30
01.1
+
TIME VOLT
On
Press the < - > or < + > soft key to adjust the Hold
Time, then press the <BACK> soft key to return to the
PV Trigger screen. In this example, the AUX MODE will
remain active for 1.1 seconds after the PV voltage is
below the PV Trigger voltage before deactivating the PV
Trigger and reconnecting to the array.
Press the <EXIT> soft key to return to the initial
PV Trigger screen
Press the <NEXT> soft key to view the ERROR OUTPUT
screen.
