AUTO MODE
COUNT
00
EXIT
NOTE:
• Auto Mode initiates when a preset interval day (1-250 days) is reached.
• The default equalize interval (EQ INTERVAL) setting is 000 day leaving the auto eq disabled.
• EQ-MPPT display indicates the Charge Controller is trying to reach the target equalize set point.
• The equalize time EQ 0:00 in Hours:Minutes displays after the equalize set point is reached.
• An incomplete equalization cycle continues into the next day unless the Charge Controller is
powered off or manually stopped. The remaining EQ time can be viewed in the Stats Menu.
• The COUNT value will be cleared to 000 when an EQ is started, manually stopped, or Charge
Controller has been powered off .
• After recharging, an EQ DONE message displays and a Float cycle begins. EQ DONE is displayed until
(1) any soft key is pressed or (2) a new day occurs for systems using an OutBack MATE.
BATTERY EQUALIZE
EXIT NEXT -EQV +EQV
Charger
Eq Misc
Logging
EXIT
43
EQ INTERVAL
000
-DAY +DAY
Volts
15.0
Aux Light
Advanced
Stats
GO
Use the <-DAY> and <+DAY> soft keys to preset the
interval day to initiate an automatic equalization cycle.
The EQ INTERVAL displays the number of days in the
interval between cycles and COUNT displays how many
days of the interval have passed. To view the MAIN EQ
screens, press the <EXIT> soft key.
Press the fi rst soft key twice to return to the MAIN Menu.
Press the < > soft key until the
Press the <GO> soft key to view the Misc screen.
is in front of Misc.
