4.8

RTM VPD EEPROM

The MVME7100ET RTM provides an 8 KB dual address serial EEPROM containing VPD
configuration information specific to the MVME7100ET RTM. Typical information that may
be present in the EEPROM may include: manufacturer, board revision, build version, date
of assembly, options present, and so on. The RTM VPD EEPROM device ID is user
selectable with the recommended value for MVME7100ET as shown in
55. Refer to the EEPROM Datasheet listed in
additional details.
4.9

Ethernet PHY Address

The assigned Ethernet PHY addresses on the MC864xD MII management (MIIM) bus is
shown in the following table. Need new table data.
Table 4-5
MC864xD Ethernet
Port
TSEC1
TSEC2
TSEC3
TSEC4
4.10

Flash Memory

The MVME7100ET is designed to provide 128MB of soldered-on NOR flash memory. Two
AMD +3.0V devices are configured to operate in 16-bit mode to form a 32-bit flash bank.
This flash bank is also the boot bank and is connected to LBC Chip Select 0 and 1. The
NOR flash is accessed via the MC864xD local bus. The table below shows memory size
and device IDs.
Table 4-6
Device Part
Number
S29GL512N10
MVME7100ET Single Board Computer Programmer's Reference (6806800K88C)
PHY Types and MII Management Bus Addresses
Function/Location
Gigabit Ethernet port 1 routed to
front panel
Gigabit Ethernet port 2 routed to
front panel
Gigabit Ethernet port routed to P2
Gigabit Ethernet port routed to P2
NOR Flash Memory Configurations
Data Bus
Bank Size
Width
32 bits 128 MB
Programming Details
Appendix B, Related Documentation, for
PHY Types
BCM5482SH
BCM5482SH
BCM5482SH
BCM5482SH
Device Size Vendor ID
512 megabit AMD-0001h
Table 4-4 on page
PHY MIIM
Address [4:0]
01
02
03
04
Device ID
7E23h
