MC864xD Interrupt Controller

The MVME7100ET uses the MC864xD integrated programmable interrupt controller (PIC)
to manage locally generated interrupts. Currently defined external interrupting devices and
interrupt assignments, along with corresponding edge/levels and polarities, are shown in
the following table.
Table 4-2
Interrupt # Edge/Level Polarity
0
1
2
3
4
5
6
7
8
9
10
11
NOTES:
1. External timers are implemented in a PLD.
2. External UARTs are implemented using a QUART.
3. Refer to the MC864xD Reference Manual listed in
for additional details regarding the operation of the MC864xD PIC.
54
MC864xD Interrupt Controller
Level Low
Level Low
Level Low
Level Low
Level Low
Level Low
Level Low
Level Low
Level Low
Level Low
Level Low
Level Low
MVME7100ET Single Board Computer Programmer's Reference (6806800K88C)
Interrupt Source
PCI Express Port 1
PCI Express Port 1
PCI Express Port 1
PCI Express Port 1
PCI Express Port 2
PCI Express Port 2
PCI Express Port 2
PCI Express Port 2
XMCspan
RTC, TEMP, Abort
PHYs
UARTs, External Timer
Related Documentation on page
Programming Details
Notes
1,2
83,
