Programming Details
Table 4-4
I2C Bus
Address
$A2
$A4
$A6
$A8
$AA
$AC
$AE
$D0
NOTES:
1. Each SPD defines the physical attributes of each bank or group of banks.
2. This is a dual address serial EEPROM.
3. The device address is user selectable using switches on the RTM. The recommended
address setting for the ADT7461 is $AA.
4.6
User Configuration EEPROM
The board provides two 64KB dual address serial EEPROMs for a total of 128KB user
configuration storage. These EEPROMs are hardwired to have device IDs as shown in
Table 4-4 on page
the EEPROM Datasheet listed in
details.
4.7
VPD EEPRO
The MVME7100ET board provides an 8KB dual address serial EEPROM containing Vital
Product Data (VPD) configuration information specific to the MVME7100ET. Typical
information that may be present in the EEPROM may include: manufacturer, board
revision, build version, date of assembly, memory present, options present, L2 cache
information, and so on. The VPD EEPROM is hardwired to have a device ID as shown in
Table 4-4 on page
Documentation, for additional details.
56
I2C Bus Device Addressing (continued)
Device Address
A2 A1 A0
Size (bytes) Device Function
(binary)
001
256 x 8
010
65,536 x 8
011
65,536 x 8
100
8192 x 8
101
8192 x 8
110
111
N/A
N/A
55, and each device ID will not be used for any other function. Refer to
55. Refer to the EEPROM Datasheet listed in
MVME7100ET Single Board Computer Programmer's Reference (6806800K88C)
DDR2 memory bank 2 SPD
User configuration
User configuration
VPD (on-board system configuration)
RTM VPD (off-board configuration)
Reserved
Reserved
DS1375 real-time clock
Appendix B, Related
Documentation, for additional
Programming Details
Notes
1
2
2
2
2, 3
Appendix B, Related
