Table 8: EPAP Interconnect Table

Cable Part Number
830-1173-68 CAT 5 Crossover
830-1173-68 Cat 5 Crossover
830-1220-XX Serial Roll Over
830-1220-XX Serial Roll Over
830-1220-XX Serial Roll Over
830-1220-XX Serial Roll Over
830-1174-XX CAT 5 Straight
830-1174-XX CAT 5 Straight
830-1174-XX CAT 5 Straight
830-1174-XX Cat 5 Straight
830-1174-XX CAT 5 Straight
830-1174-XX CAT 5 Straight
830-1174-XX CAT 5 Straight
830-1174-XX CAT 5 Straight
830-1173-68 Optional
830-1173-68 Optional
830-1173-68 Optional
830-1173-68 Optional
910-6535-001 Revision D, February 2014
To
Switch A port 1
Switch A port 2
Card / Server A, (P3)
830-1407-XX
Card /Server A, (P4)
830-1407-XX
Card /Server A, (P6)
830-1407-XX
Card /Server B, (P6)
830-14070-XX
Card /Server A Port A (P2)
830-1102-03
Card /Server B Port A (P2)
830-1102-03
Card /Server A Port A (P3)
830-1102-03
Card /Server B Port A (P3)
830-1102-03
Card /Server A Port B (P2)
830-1102-03
Card /Server B Port B (P2)
830-1102-03
Card /Server A Port B (P3)
830-1102-03
Card /Server B Port B (P3)
830-1102-03
Switch A port 23 (CAT 5)
Crossover
Switch A port 24 (CAT 5)
Crossover
Switch B port 23 (CAT 5)
Crossover
Switch B port 24 (CAT 5)
Crossover
ExAP or LSMS Network Integration
From
Switch B port 1
Switch B port 2
Card /Server B, (P4)
830-1407-XX
Card /Server B, (P3)
830-1407-XX
Switch A Console Port
Switch B Console Port
Customer Provisioning Network
ETH01
Customer Provisioning Network
ETH01
Switch A Port 3 ETH02
Switch A Port 4 ETH02
Switch B Port 3 ETH03
Switch B Port 4 ETH03
Switch A Port 5 ETH04
Switch A Port 6 ETH04
Switch C port 23
Switch C port 24
Switch D port 23
Switch D port 24
