Hardware and Installation Manual
LED Name
Act LED B2
Link LED A1
Link LED A2
Link LED B1
Link LED B2
910-6535-001 Revision D, February 2014
HW/SW Controlled
Description
HW
Flashing Green - Link Activity
HW
Green - 10/100 Link Speed
Amber - 1000 Link Speed
HW
Green - 10/100 Link Speed
Amber - 1000 Link Speed
HW
Green - 10/100 Link Speed
Amber - 1000 Link Speed
HW
Green - 10/100 Link Speed
Amber - 1000 Link Speed
E5-APP-B Card Overview
