One Server Status indicator (A)
Four E-Net link and Active LED status indicators (B)
Two drive module status indicators (C)
One Card Eject status indicator (D)
For more information about the diagnostics that manage these alarm and status indicators, see
Card
Diagnostics.
E5-APP-B Card Installation
A single E5-APP-B card is installed in two adjacent EAGLE shelf slots. To install two E5-APP-B cards
for redundancy (the recommended configuration), the EAGLE must have room to install two
double-width cards.
E5-APP-B Card Components
The E5-APP-B card consists of the following standard hardware components:
Dual Core 2.66GHz 64-bit processor
Active/Trial BIOS architecture
1333 megahertz (MHz) processor front side bus speed
8 GB DDR2 DRAM
Light Emitting Diode (LED) status display
Hardware monitors that read and report:
Supply and core voltages
Fan alarm inputs
Ambient and processor temperatures
Two drive modules (Field-replaceable Units (FRUs))
E5-APP-B Card Interfaces
The E5-APP-B card includes interfaces for accommodating expansion, control and configuration,
network connectivity, and peripheral support.
Table 6: E5-APP-B Card Interfaces
910-6535-001 Revision D, February 2014
shows the basic interfaces on the E5-APP-B card.
E5-APP-B Card Overview
E5-APP-B
34
