Hardware and Installation Manual

Figure 13: E5-APP-B Card Inject Hardware Switch, LOCKED

7. WAIT for the E5-APP-B Eject Status LED to go from blinking red to off.

Removing an E5-APP-B Card

Procedure - Remove E5-APP-B card
Refer to the Hardware and Installation manual for E5-APP-B on halting the E5-APP-B Card software.
1. On the APP-B card, slide the Ejector switch (4) up to the UNLOCKED position (see
E5-APP-B Card Eject Hardware Switch,
Caution: If the Ejector switch goes from locked to unlocked and the E5-APP-B card
is in service, the card will halt.
910-6535-001 Revision D, February 2014
Installing and Removing E5-APP-B Cards
UNLOCKED).
Figure 14:
44
