Hardware and Installation Manual
To locate the part number information, use the indicated procedure below:
E5-APP-B card, use
Drive module assembly, use
Locating E5-APP-B Card Part Number Information
The part number information for the E5-APP-B card is located on the label on the faceplate of the
E5-APP-B card. Use this label to verify the correct part number if you ever need to replace the E5-APP-B
card.
1. Request assistance from the Customer Care Center to determine which slot (1 through 17) contains
the E5-APP-B card that needs to be replaced.
2. See Locating Drive Module Assembly Part Number Information
E5-APP-B card on the label.
Warning: Always wear an ESD wrist strap grounded to the bench or frame when
working on electronic components.
Locating Drive Module Assembly Part Number Information
The part number information for drive module assemblies is located on the label on the drive module
assembly. Use this label to verify the correct part number if you ever need to replace a drive module
assembly. See Figure 1: E5-APP-B Card Label

Figure 1: E5-APP-B Card Label Locations

Serial Number Label (1)
CLEI Label (2)
Part Number Label (3)
Revision Label (4)
910-6535-001 Revision D, February 2014
Locating E5-APP-B Card Part Number Information
Locating Drive Module Assembly Part Number Information
Locations.
About This Manual
for the location information of each
