To transfer controls from any of the top five rows of encoders to
the bottom row of encoders:
Hold the Start key (Windows) or Control key (Mac) and
press the Flip switch that corresponds to the encoder row.
To exit Flop mode:
Press either of the lighted Flip switches.
When D-Control is in Make Inactive mode or Assign mode,
it is temporarily taken out of Flop mode, but the Flip
switches remains lit. When you exit Make Inactive mode or
Assign mode, controls return to their flopped positions.
Make Inactive Controls
The Make Inactive controls are used to make tracks, inputs,
outputs, sends, or plug-ins inactive. Each switch puts D-Con-
trol into a temporary Make Inactive mode in which elements
are made inactive or reactivated. The switch flashes while
Make Inactive mode is in effect.
Inputs Inactive
switch
Inputs
Sends Inactive
switch
Sends
Make Inactive Controls
Making a Track Inactive
In Make Inactive mode, channel Select switches are lit on all
tracks.
To toggle a track inactive/active:
Press any of the Make Inactive switches.
1
Press the channel strip Select switch for each track you want
2
to deactivate or activate.
Press the flashing Make Inactive switch to exit Inactive
3
mode.
Inputs Inactive Switch
The Inputs switch invokes Inputs Inactive mode and displays
channel inputs in the bottom row of encoders. The By-
pass/Mute/Pre switch on the bottom encoder toggles the in-
put inactive and active.
54 D-Control Guide
Make Inactive
Outputs Inactive
switch
Outputs
Plug-ins Inactive
switch
Plug-ins
Outputs Inactive Switch
The Outputs switch invokes Outputs inactive mode and dis-
plays the main channel outputs in the bottom row of encod-
ers. The Bypass/Mute/Pre switch on the bottom encoder tog-
gles the output inactive and active.
Sends Inactive Switch
The Sends switch invokes Sends Inactive mode and displays
the channel's sends on its encoders. The Bypass/Mute/Pre
switch on each encoder toggles the corresponding send inac-
tive and active.
Plug-ins Inactive Switch
The Plug-ins switch invokes Plug-ins Inactive mode and dis-
plays a channel's inserts on its encoders. The Bypass/Mute/Pre
switch on each encoder toggles the corresponding insert inac-
tive and active.
To toggle an input, output, send, or plug-in active/inactive:
Make sure the channel is showing the top-level view for the
1
element you want to make active/inactive.
Press a Make Inactive switch to enter the appropriate Make
2
Inactive mode.
Press the Bypass/Mute/Pre switches on encoders to deacti-
3
vate or reactivate their corresponding track elements.
Press the flashing Make Inactive switch to exit Inactive
4
mode.
Plug-in Automation Controls
The Plug-in Automation controls are used to enable parame-
ters for automation and to place them in automation safe
mode.
Plug-in Automation
Enable Parameter
switch
Enab Para
Plug-in Automation controls
Enable Parameters Switch
The Enable Parameters switch lets you enable parameters for
automation by touching or pressing their controls.
In Enable Parameters mode, the Enable Parameters switch is
lit. While in this mode, the Auto LED for any rotary encoder
enabled for automation is lit red, and the switch for any pa-
rameter enabled for automation is lit.
Automation Safe
switch
Safe
