Overview

1 Overview
1.1

Features

Three 5 V power supply options: power jack, USB connector or daughterboard
Boot from user Flash, test Flash or SRAM
Audio play and record
64 Mbyte MicroSD Card
Type A and Type B smartcard support
8 Mbyte serial Flash
2
I C/SMBus compatible serial interface temperature sensor
Two RS-232 communication channels with support for RTS/CTS handshake on one
channel
IrDA transceiver
USB 2.0 full speed connection
CAN 2.0A/B compliant connection
Induction motor control connector
JTAG, SWD and trace tool support
240x320 TFT color LCD
Joystick with 4-direction control and selector
Reset, wakeup, tamper and user push buttons
Four LEDs
RTC with backup battery
Extension connector for daughterboard or wrapping board
1.2

Order code

To order the STM32F10x 128 K evaluation board, use the order code STM3210B-EVAL.
