UM0426
3.3

Analog input connector CN3

Figure 10. Analog input connector CN3 (top view)
Table 14.
Pin number
3.4

Power supply connector CN4

The STM3210B-EVAL board can be powered from a DC 5 V power supply via the external
power supply jack (CN4) shown in
Figure 11. Power supply connector CN4 (front view)
www.BDTIC.com/ST
Analog input connector CN3
Description
1 GND
2 GND
3 GND
DC +5V
Doc ID 13472 Rev 5
1
2
5
4
3
Pin number
4
5
Figure 11. The central pin of CN4 must be positive.
Connectors
Description
GND
Analog input/PC1
GND
17/46
