UM0426
Table 20.
Pin
48
50
Table 21.
Pin
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39
41
43
45
47
49
2
4
6
www.BDTIC.com/ST
Daughterboard extension connector CN12 (continued)
Description Alternate function
+3V3
GND
Daughterboard extension connector CN13
Description Alternate function
GND
NC
PE6 Debug TraceD3
PE4 Debug TraceD1
PC13 Tamper key
RESET# RESET# button
PE1 Joystick Left
PB9 User button
PB7 Temperature sensor
D5V
PB4 Debug nTRST
NC
PD6 USART2
PD4 USART2
PD3 USART2
PD1 CAN_TX
PC12 MicroSD Card
PC10 IrDA
PA14 Debug TCK
GND
PA12 USB
PA10 USART1_RX
PA8 LCD
PC8 LED3
PC6 LED1
NC
PC13 Tamper button
PE5 Debug TraceD2
Doc ID 13472 Rev 5
How to disconnect from function block on
STM3210B-EVAL board
- -
- -
How to disconnect from component on
STM3210B-EVAL board
- -
-
-
-
-
Remove R74
Remove R78
Remove R114
- -
JP10 is not fitted
- -
Remove R77
-
Remove R79
-
Remove R81
-
-
- -
-
Remove R70
-
Remove R6
Remove R8
Remove R62
-
Connectors
23/46
