Install end caps
1. Install two screws securing right end cap using a Phillips screwdriver.
2. Repeat step for left end cap.
Install motor cover
1. Place the motor cover into position vertically by aligning the two tabs and four plastic connectors.
Two plastic connectors are mounted in the front cover and two in the motor cover. If motor cover
top does not fit properly, loosen the side screws as needed.
2. Tighten the two front cover screws using a Phillips screwdriver.
Be sure the screws are securing the motor cover's tabs.
Center and tension the running belt
1. Plug the power cord into the power outlet.
2. Turn the main power switch to the on (I) position.
3. Tap the Quick Start icon.
Cybex 770T/790T Treadmill Part Number
Page 174 of 261
Item Description
1 Screws
2 Right end cap
Item Description
1 Motor Cover
2 Front Cover
3 Screws
4 Plastic Connectors
Qty.
2
1
Qty.
1
1
2
4
