CYBEX 770T Service Manual page 145

Remove top steps
1. Remove the right top step by inserting a long 3/8" drive socket extension into the right top step and
prying backwards.
2. Remove right top step.
3. Repeat steps 1 and 2 for left top step.
Remove rear roller
1. Remove the two rear roller bolts, washers, bushing and rear roller nut (one roller bolt on each side)
using a 3/4" Socket wrench.
Loosen each bolt evenly, making sure not to loosen either bolt too many turns before moving to the
other bolt.
2. Lift one side of the rear roller and slide the roller out of the running belt.
Cybex 770T/790T Treadmill Part Number
Page 145 of 261
Item Description
3/8" Drive Socket Exten-
1
sion
2 Right Top Step
Item Description
1 Rear roller nut
2 Rear roller
3 Bushing
4 Washer
5 Bolt
Qty.
1
1
Qty.
1
1
1
1
1
