Install top steps
1. Install right top step by placing in position and inserting a long 3/8" drive socket extension into top
step.
2. Pry the long 3/8" drive socket extension forwards to secure right top step.
3. Repeat steps 1 and 2 for left top step.
Install end caps
1. Install two screws securing right end cap using a Phillips screwdriver.
2. Repeat step for left end cap.
Complete installation
1. Plug the power cord into the power outlet.
2. Verify the power cord is not being pinched under the front of the treadmill.
3. Operate the unit at all levels to verify proper operation.
Cybex 770T/790T Treadmill Part Number
Page 125 of 261
Item Description
3/8" Drive Socket Exten-
1
sion
2 Right Top Step
Item Description
1 Screws
2 Right end cap
Qty.
1
1
Qty.
2
1
