Interconnect Module
5
Connector
J1
J3
J4
J5
S1
Screw terminals
The enclosure of the card is a standard Phoenix DIN rail mounting system. Alternatively, the enclosure may be
removed, and the card mounted to other systems via the 3.5 mm mounting holes located on the corners of the card.
The pinout descriptions that follow provide a detailed illustration of the IM-1000's connections. Please observe the
differences between the DC brush and brushless DC and stepping motor versions. The screw terminal numbers
correspond to the pinout description for Prodigy/CME PC/104 card in the following way:
Prodigy/CME PC/104
H1
H2
The following table lists the functions of the remaining screw terminals:
Screw Terminals Function
101, 103
102, 104, 105
106
107
108
The Prodigy/CME PC/104 supplies 5V DC to pins J5-7, J5-25, J6-7, and J6-25 through a 1 Amp fuse to power
encoders. When the IM-1000's jumpers JP1, JP2, JP3 and JP4 are installed 1-2, this 5V is passed on to screw terminals
7, 25, 57, and 75, respectively. Alternatively, it is also possible to use an external power supply in the range of 5 - 12
VDC for the encoders. To do this, install jumpers JP1, JP2, JP3 and JP4 on pins 2-3 and connect the external power
to screw terminal 106 and its ground to 107. This external power will be limited to 1 Amp by fuse F1.
Connections to J3 (the OPTO22 connector) are as follows:
Prodigy/CME PC/104
J5/J6
J5-36
J5-37
J5-38
J5-39
J5-36
J5-37
J5-38
J5-39
J5-41
J5-42
J5-43
J5-44
J6-41
J6-42
J6-43
J6-44
J6-40
J6-45
J6-40
90
Description
100-position connector
OPTO22 connector
50-position connector
50-position connector
External hardware reset button
(3) 100-terminal connection blocks for connecting to
one 100-position, or two 50-position cables.
IM-1000 Screw Terminal
J4 1-50
J5 51-100
5V from J1 through 1 Amp fuse F2
GND
External power in
GND
Unused
IM-1000
J3
49
47
45
43
41
39
37
35
33
31
29
27
25
23
21
19
17
15
13
11
Description
5V if JP5 jumper is installed
DigitalIn0
DigitalIn1
DigitalIn2
DigitalIn3
DigitalIn4
DigitalIn5
DigitalIn6
DigitalIn7
DigitalOut0
DigitalOut1
DigitalOut2
DigitalOut3
DigitalOut4
DigitalOut5
DigitalOut6
DigitalOut7
AmpEnable1
AmpEnable2
AmpEnable3
