If serial communication is correctly established, a set of object graphics loads into the Project window to
the left, as shown in the following figure.
For example for a four axis Prodigy card, you see the card name next to an icon of a card, and below that you see four
axis icons, one for each available axis of the motion card. Highlighting (single clicking) either the card icon or one of
the axis icons with the mouse is used to select specific cards or axes, and is useful later on in the first time system
verification.
If serial communications are not correctly established, after approximately 10 seconds a dialog box appears indicating
that a Communications Timeout Error has occurred. If this is the case, recheck your connections and repeat from step
1 above. If after repeated attempts a connection can still not be established, call PMD for assistance.
