Pin
Number Signal
4 axis 4, pulse -
5 axis 1, direction +
6 axis 1, direction -
7 axis 4, direction +
8 axis 4, direction -
9 axis 2, pulse +
10 axis 2, pulse -
4.2.12 Power Connectors
J21 can be used to provide +5V power to the card. If the Prodigy/CME PC/104 card is powered through the PC/
104 bus then this connection is not necessary, however it is often used during prototyping for convenience. This
connector is used with the wall outlet power supply cable set PW-2001-KIT which is included with DK (Developer's
Kit) version of the Prodigy/CME-PC/104 card.
J21 is a 2 pin 1.50 mm pitch header. The table below shows the pin connections:
Pin #
1
2
To minimize the risk of unintended machine motion during powerup, care should be taken to control the overall
powerup sequence of the Prodigy/CME card and connected system motion amplifiers. The recommended se-
quence is to first powerup the Prodigy/CME card, followed by powerup of the motion amplifiers. The time delay
to ensure stable operation of the control electronics before powering up the amplifiers varies depending on the
system's power supplies and configuration, but a typical safe figure is 500 mSec - 1,000 mSec.
4.2.13 Connector Parts Reference
The following table is supplied as a reference only. "(V)" indicates the vertical mounting configuration of the Prodigy/
CME PC/104 card, while "(H)" indicates the horizontal configuration.
Label Description
J5 & J6 GP Connector
J9 Option Connector
J3,J4 Synch Connector
J17 Serial Connector
J16 CAN Connector
J15 Ethernet Connector
J1 Extension Connector
J12 Pulse & Direction
J21 Power Connector
Prodigy/CME PC/104 User's Guide
Pin
Number Signal
14 axis 1, pulse -
15 axis 2, direction +
16 axis 2, direction -
17 axis 3, pulse +
18 axis 3, pulse -
19 GND
20 GND
J21 Connector
Vcc (+5V)
GND
Card Part Number
Samtec TSM-125-01-L-DV
Samtec TSM-125-01-L-DV
Molex 53261-0271
Molex 87832-1020
Molex 87832-0820
Molex 87832-1020
Samtec TMM-123-01-L-D-SM
Samtec TSM-110-01-L-DV
Molex 87438-0243
Electrical Reference
Connector Mate
Samtec IDSD-25-X-X
Samtec IDSD-25-X-X
Molex 51021-0200
Molex 51110-1051(housing) and
50394-8100 (crimp pin)
Molex 51110-0851(housing) and
Molex 50394-8100 (crimp pin)
Molex 51110-1051(housing) and
50394-8100 (crimp pin)
Samtec IDSD-10-X-X
Molex 87439-0200 (housing) and
87421-0000 (crimp pin)
4
