4.4.9 Cable-4505-01-R
PMD Part #: Cable-4505-01.R
Description: 10-pin dual header to RJ45 cable
Length: 5.0 feet
Cable: 4 pair, 24 AWG, Cat 5/5e
Wiring: See table.
4.4.10 Cable-4371-01.R
PMD Part #: Cable-4371-01.R
Description: 20-pin to 20-pin connector ribbon cable
Length: 3.0 feet
Cable: 20 wire 0.050" pitch, 28 AWG flat ribbon cable
Wiring: Straight through
4.5 Environmental and Electrical
Ratings
Storage temperature:
Operating temperature:
Power requirements:
Supply voltage limits:
Analog (DAC) output range:
Analog input range:
Digital I/O voltage range:
Digital outputs drive capacity:
CAN communications:
Serial communications:
Ethernet communications:
Prodigy/CME PC/104 User's Guide
-40 to +125 degrees C (-40° F to +257° F)
0 to +70 degrees C (32° F to +158° F)
4.8V to 5.25V operating range, 0.8A (no outputs on)
-0.3V to +7V
-10.0V to +10.0V, ± 3mA min/axis, short circuit protected
0 to 3.3V, 1.4 kOhm input impedance
0V to 5V, TTL thresholds, inputs pulled up to 5V through 4.7 kOhm resistors
DC output source or sink current: ± 50mA
2.0B compliant, non-isolated, 1 Mbps
RS232 signaling or RS485 Full or Half Duplex (data only)
10/100BASE-TX (10/100 Mbps)
J16 Pin Signal Connects to:
1 EthernetTx+ 1
2 EthernetTx- 2
3 EthernetRx+ 3
4 no connect 4
5 no connect 5
6 EthernetRx- 6
7 no connect 7
8 no connect 8
9 no connect -
10 no connect -
Electrical Reference
4
85
