2.Operation
In This Chapter

Card Function Summary

Magellan Motion Processor Functions

Magellan-Controlled Functions

C-Motion Engine Functions

Communications Functions

General Card Functions

Signal Processing and Hardware Functions

Software Libraries
The Prodigy/CME PC/104 products are high-performance card-based motion controllers for DC brush, brushless DC,
pulse & direction, and microstepping motors. These cards are based on Magellan Motion Processors, which perform
motion command interpretation and numerous other real-time functions. The '/CME' series Prodigy cards include a
powerful C-Motion Engine module which allows C-Motion application code to be downloaded and executed directly
on the motion card, improving run time performance, enabling distributed control architectures, and allowing a
complete machine controller to be hosted on a single card.
The following diagram provides a functional block diagram of the Prodigy/CME PC/104 card:
