4.4.2 Cable-2003-01.R
PMD Part #: Cable-2003-01.R
Description: 50-pin connector to 50-pin connector ribbon cable.
Length: 3.0 feet
Cable: 50 pair, 30 AWG, shielded round
Wiring: Straight through
4.4.3 Cable-4301-01.R
PMD Part #: Cable-4301-01.R
Description: 10-pin dual header (J17) to DB-9 cable
Length: 1.0 feet
Cable: 9 conductor, 26 AWG, untwisted
Wiring: See table.
4.4.4 Cable-4355-01.R
PMD Part #: Cable-4355-01.R
Description: Male DB-9 Dual Serial to two
single-channel female DB-9 cable
Length: 5.0 feet
Cable: (2) 3 conductor, 26 AWG, Untwisted,
shielded, UL STYLE 2464
Note: Dual female DB-9 ends are labeled "Port1" and "Port2."
Wiring: See table.
Prodigy/CME PC/104 User's Guide
J17 Pin Signal Connects to
1 + 1
RS485Rcv
2 Srl1Xmt 6
3 Srl2Rcv/ 2
–
RS485Rcv
4 Srl1Rcv 7
5 Srl2Xmt/ 3
+
RS485Xmt
6 Srl2Xmt/ 8
+
RS485Xmt
7 – 4
RS485Xmt
8 GND 9
9 GND 5
10 no connect -
Connects to
Male dual female
DB-9 Pin Signal DB-9 Pin:
1 RS485Select -
2 Srl1Xmt Port1-2
3 Srl1Rcv Port1-3
4 No connect -
5 GND Port1-5, Port2-5
-
6 +
RS485Rcv
7 Srl2Rcv/ Port2-3
-
RS485Rcv
8 Srl2Xmt/ Port2-2
+
RS485Xmt
9 - -
RS485Xmt
