Redboot Command Overview - Comtrol DeviceMaster MOD Series Hardware Installation And Configuration Manual

RedBoot Command Overview

auth
{noaccess, none, basic, md5, invalid}
baudrate [-b <rate>]
boardrev†
cache [ON | OFF]
channel [-1|<channel number>]
chassis
cksum -b <location> -l <length>
cpufreq
delaycal <passes>
disable
dump -b <location> [-l <length>] [-s]
[-1|-2|-4]
eepromvers [ver]
fis {cmds}
flash
go [-w <timeout>] [-c] [-n] [entry]
help <topic>
history
hwflags [flags]
ip [addr mask gateway]
load [-r] [-v] [-h <host>]
[-p <TCP port>]
[-m <varies>]
[-c <channel_number>]
[-b <base_address>]
<file_name>
loop 232|422|int port-number
mac†
DeviceMaster MOD | UP Hardware Installation and Configuration Guide: 2000630 Rev. B
The following table is an overview of RedBoot commands available. After
accessing RedBoot, you can review the list of commands online by entering help
and pressing the Enter key.
For more detailed information, see the eCos Reference Manual that you can
download from: http://downloads.comtrol.com/dev_mstr/UP/software/redboot/
user_guide.
RedBoot Commands
Sets or displays web authentication. The default is set to none, which
means that there is no authentication required to access the web
server.
To deny access to the web server, click noaccess or invalid. If access is
attempted, a message appears to notify the user that access is denied.
To configure the web server to request an un-encrypted password, click
basic. To configure the web server to request an encrypted password,
click md5. (Some browsers do not support the md5 command.)
Set/Query the system console baud rate.
Displays the board revision.
Manages machine caches.
Displays or switches the console channel.
Displays chassis information.
Computes a 32-bit checksum [POSIX algorithm] for a range of memory.
Show/Set CPU clock frequency.
Calibrate SDRAM clock delay.
Disables automatic load of the default application.
Displays (hex dump) of a range of memory.
Show/set EEPROM version.
Manages flash images. See Chapter 2 of the
{cmds} information.
Shows flash information.
Executes code at a location.
Displays available RedBoot commands.
Displays command history.
Show/set hardware feature flags.
Displays or sets the IP address configuration.
Loads a file from TFTP server or XModem.
Runs loopback test on port. The DeviceMaster Serial Hub does not
support this command.
Displays Ethernet MAC address.
RedBoot Procedures
eCos Reference Manual
RedBoot Procedures - 77
for
