Power Consumption

Parameter
+5 V
+5 V available at I/O connector

Environmental

Parameter
Operating temperature range
Storage temperature range
Humidity

Mechanical

Parameter
Card dimensions (L × W × H)

DAQ-Sync connector

Parameter
Connector type
Compatible cables
Pin Signal Name
1 DS A/D START TRIGGER
2 GND
3 DS A/D STOP TRIGGER
4 GND
5 DS A/D CONVERT
6 GND
7 DS D/A UPDATE
8 GND
9 DS D/A START TRIGGER
10 GND
11 RESERVED
12 GND
13 SYNC CLK
14 GND
