Analog I/O calibration

Parameter
Recommended warm-up time
Calibration
Onboard calibration reference
Calibration interval

Digital I/O

Parameter
Digital type
Number of I/O
Configuration
Input high voltage
Input low voltage
Output high voltage
(IOH = –32 mA)
Output low voltage
(IOL = 32 mA)
Data transfer
Power-up / reset state
