PCI-DAS6030 & PCI-DAS6032 User's Guide

Signal connections

SCSI connector

Connector type
Compatible cables
Compatible accessory products
(with the C100HD50-x cable)
Compatible accessory products
(with the C100MMS-x cable)
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Board connectors, cables, accessory equipment
Shielded SCSI 100 D-type
C100HD50-x, unshielded ribbon cable. x = 3 or 6 feet (Figure 1)
C100MMS-x, shielded round cable. x = 1, 2, or 3 meters (Figure 2)
ISO-RACK16/P
ISO-DA02/P
BNC-16SE
BNC-16DI
SCB-100
10
Installing the PCI-DAS6030 and PCI-DAS6032
CIO-MINI50
CIO-TERM100
SCB-50
