Setting up VPLEX
Task 14: Enable the
WAN ports
Task 15: Enable the
front-end ports
66 EMC VPLEX with GeoSynchrony 4.1 Installation and Setup Guide
2. Type the following command to create the meta-volume and a mirror:
Note: You can copy a storage volume name from the ll output and paste it into the
following command. To do this, highlight the volume to select it, and then right-click at the
point in the command where you want to paste the volume.
meta-volume create -n <meta-volume_name> -d <storage-volume_1_
name>,<storage-volume_2_name>
where:
• <meta-volume_name> is a name you are assigning to the meta-volume.
• <storage-volume_1_name> is the VPD (Virtual Private Database) name of the
meta-volume.
• <storage-volume_2_name> is the VPD name of the mirror.
The mirror can consist of multiple storage volumes (which will become a
RAID 1), in which case you would include each additional volume, separated
by commas. For example:
<storage-volume_1_name>,<storage-volume_2_name>,<storage-volume_3_name>
3. Type the following command to display the meta-volume status:
ll /clusters/cluster-2/system-volumes/<meta-volume_name>
In the output, verify that the attribute active shows a value of true.
4. Type the following command to display the cluster status:
cluster status
The meta-volume takes time to resynchronize with the mirror. Wait until the
output from cluster status shows an operational-status of ok before proceeding.
Also verify that there are no health indications in the output.
Output example:
Cluster cluster-2
operational-status:
transitioning-indications:
transitioning-progress:
health-state:
health-indications:
1. Type the following command from the VPlexcli prompt, to enable all WAN COM
ports in the cluster:
set /**/*4-FC0[2-3]::enabled true
2. Type the following command to display all director ports in the cluster:
ll /engines/engine-2-*/**/ports
In the output, verify that all ports numbered A4-FC02, A4-FC03, B4-FC02, or
B4-FC03 have a port status of up.
From the VPlexcli prompt, type the following command:
configuration enable-front-end-ports
ok
ok
