Procedure

Running the IBERT Demonstration for Duals 245 and 267

Running the IBERT demonstration for Duals 245 and 267 is described in this section. See
also

GTP Transceiver Clock Connections

Refer to
SuperClock-2 module to the reference clock SMAs of GTP Duals 245 and 267 on the SP623
board. In other words, for each row in
corresponding destination SMA.
For example, connect CKOUT1_P (J5) to 245_REFCLK0_P (J80).
Table 3: Duals 245 and 267 Reference Clock Connections

GTP TX/RX Connections

Refer to
SMAs in GTP Duals 245 and 267. In other words, for each row in
transmitter SMA with its corresponding receiver SMA.
For example, connect 245_TX0_P (J74) to 245_RX0_P (J48) on the SP623 board.
Table 4: Duals 245 and 267 TX/RX Connections
18
Running the IBERT Demonstration for Duals 101 and 123, page
Table 3 and use four SMA cables to connect the output clock SMAs from the
Source
SuperClock-2 Module
Net Name SMA Connector
CKOUT1_P
CKOUT1_N
CKOUT2_P
CKOUT2_N
Table 4 and use eight SMA cables to connect the transmitter SMAs to the receiver
Transmitter
Net Name SMA Connector
245_TX0_P
245_TX0_N
245_TX1_P
245_TX1_N
267_TX0_P
267_TX0_N
267_TX1_P
267_TX1_N
www.xilinx.com
Table 3, connect the source SMA with its
Net Name
J5 245_REFCLK0_P
J6 245_REFCLK0_N
J7 267_REFCLK0_P
J8 267_REFCLK0_N
Net Name
J74 245_RX0_P
J75 245_RX0_N
J78 245_RX1_P
J79 245_RX1_N
J86 267_RX0_P
J87 267_RX0_N
J90 267_RX1_P
J91 267_RX1_N
SP623 IBERT Getting Started Guide
9.
Destination
SP623 Board
SMA Connector
J80
J81
J92
J93
Table 4, connect the
Receiver
SMA Connector
J48
J73
J76
J77
J84
J85
J88
J89
UG752 (v1.0.1) January 26, 2011
