Ordering Information; Bill Of Materials - Analog Devices EVAL-ADAU1777Z User Manual

UG-1055

ORDERING INFORMATION

BILL OF MATERIALS

Table 4.
Qty Designator
2 C1, C2
9 C17, C19, C26, C27, C31,
C35, C36, C41, C42
1 C23
1 C24
2 C3 C5
3 C34, C37, C40
1 C39
6 C4, C15, C33, C38, C43, C46
2 C44, C45
17 C6, C7, C9, C11 to C14,
C20 to C22, C25, C28 to C30,
C32, C47, C48
1 D1
2 D2, D3
1 J1
2 J13, J16
6 J18 to J23
1 J2
2 J3, J14
1 J4
1 J5
2 J6 to J7
6 J8, J10 to J12, J15, J17
1 J9
1 L2
4 MTH1 to MTH4
1 R1
1 R10
2 R14, R15
12 R16, R17, R19 to R22, R43,
R46, R49, R51, R58, R59
13 R18, R23 to R25, R32 to R40
1 R2
1 R26
1 R27
1 R28
1 R29
1 R3
2 R30, R31
6 R41, R47, R52, R55 to R57
3 R44, R45, R50
5 R4 to R8
Description
Capacitor, ceramic, 47 µF, 6.3 V, X7R, 1210
Multilayer, ceramic, 10 V, X7R (0805)
Multilayer, ceramic, 25 V, NP0 (0603)
Multilayer, ceramic, 16 V, X7R (0603)
Multilayer, ceramic, 50 V, NP0 (0402)
Multilayer, ceramic, 10 V, X7R (0603)
Multilayer, ceramic, 16 V, X7R (0603)
Do not stuff
SMD tantalum capacitor, SMD, D, 6.3 V
0.10 µF, 16 V, ceramic capacitor, X7R, 0402
(1005 metric), 0.039" L x 0.020" W (1.00 mm ×
0.50 mm)
Green diffused, 10 millicandela, 565 nm, 1206
Schottky, 30 V, 0.5 A, SOD123, diode
10-way, shroud, polarized, header
2-pin header, unshrouded, jumper, 0.10"
Sterero mini jack, SMT
Mini power jack, 0.08", R/A, TH
3-pos, SIP, header
12-way, unshrouded
2-pin header, unshrouded, jumper, 0.10"
12-way socket, unshrouded
2-pin header, unshrouded, jumper 0.10"; use
shunt Tyco 881545-2
10-way, unshrouded
2.2 µH inductor
Nylon screw pan, Phillips 4-40 and hex
standoff 4-40 nylon, 1/2" standoff RND, 4-
40THR, 0.500" L, alim
Chip resistor, 1%, 125 mW, thick film, 0805
Chip resistor, 1%, 63 mW, thick film, 0402
Chip resistor, 1%, 63 mW, thick film, 0402
Do not stuff
Chip resistor, 1%, 63 mW, thick film, 0402
Do not stuff
Chip resistor, 1%, 63 mW, thick film, 0402
Chip resistor, 1%, 63 mW, thick film, 0402
Chip resistor, 1%, 63 mW, thick film, 0402
Resistor, SMD, 49.9 Ω, 1%, 1/16 W, 0402
Chip resistor, 1%, 100 mW, thick film, 0603
Chip resistor, 1%, 63 mW, thick film, 0402
Chip resistor, 1%, 63 mW, thick film, 0402
Chip resistor, 1%, 63 mW, thick film, 0402
Chip resistor, 1%, 63 mW, thick film, 0402
Rev. 0 | Page 24 of 25
EVAL-ADAU1777Z User Guide
Part Number
GCM32ER70J476KE19L
GRM21BR71A106KE51L
C1608C0G1E103J
GRM188R71C105KA12D
GRM1555C1H220GA01D
GRM188R71A225KE15D
EMK107BJ105KA-TR
Do Not Stuff
TR3D477M6R3C0200
GRM155R71C104KA88J
SML-LX1206GW-TR
MBR0530T1G
N2510-6002RB
PBC02SAAN; or cut
PBC36SAAN
SJ-3523-SMT
RAPC722X
PBC03SAAN; or cut
PBC36SAAN
PBC06DAAN, or cut
PBC36DAAN
PBC02SAAN; or cut
PBC36SAAN
PPPC062LFBN-RC
PBC02SAAN; or cut
PBC36SAAN
PBC05DAAN, or cut
PBC36DAAN
LQH32PN2R2NN0L
NY PMS 632 0025 PH and
1903C
ERJ-6ENF1000V
ERJ-2RKF1001X
CRCW04022K67FKED
OPEN
MCR01MZPF1002
OPEN
ERJ-2RKF1373X
ERJ-2RKF3743X
ERJ-2RKF1623X
MCR01MRTF49R9
ERJ-3EKF1000V
MCR01MZPF1000
CRCW040249K9FKED
ERJ-2RKF2001X
RMCF0402FT33R2
Manufacturer
Murata
Murata ENA
TDK Corp
Murata ENA
Murata ENC
Murata ENA
Taiyo Yuden
Do Not Stuff
Vishay/Sprague
Murata
Lumex Opto
On Semiconductor
3M
Sullins Electronics
Corp
CUI Inc.
Switchcraft, Inc.
Sullins
3M
Sullins Electronics Corp
3M
Sullins Electronics Corp
3M
Murata Electronics
Keystone Electronics
and B&F Fastener
Panasonic EC
Panasonic EC
Vishay/Dale
Do Not Stuff
Rohm
Do Not Stuff
Panasonic ECG
Panasonic ECG
Panasonic ECG
Rohm
Panasonic EC
Rohm
Vishay/Dale
Panasonic EC
Stackpole
