DOWNLOADING THE PROGRAM TO THE DSP

To compile and download the code to the DSP, click Link-

Compile-Download in the main toolbar of

SigmaStudio

(see Figure 28). Alternately, press the F7 key.

Figure 28. Link-Compile-Download

If the project does not compile correctly, an error displays

(see Figure 29). If an error displays, return to

SigmaStudio

and check the configuration for mistakes.

When the project compiles, the signal flow runs on the

evaluation board, and the audio passes from the input to the

output. The volume can be changed in real time by using the

buttons on the board.

Figure 29. Compile Error
