1.2 Handling of the plusoptiX R09
The plusoptiX R09 is an optical electronic measuring device. The construction and
functionality of the plusoptiX R09 is very similar of a video camera / camcorder. So,
please handle the device as carefully as you would use your own camcorder. If you
follow this advice, the plusoptiX R09 will last you for many years without any trouble.
1.3 Exclusive use of the plusoptiX R09
The exclusive use the plusoptiX R09 device is to measure dynamic refractive data,
asymmetry of the corneal reflexes, pupil size and pupil distance in real time. Both eyes
are measured at the same time (binocular) from one meter (3.3 ft) away from the
patient.
Note: The measurement is from one meter distance to the patient and so +1.00 dpt
accommodation is included into the measurement result.
This measurement setup should only be used for research purposes. Also it
should only be used by trained persons.
1.4 Operation of the plusoptiX R09
Check all cable connections from the mains as well as the VGA cable
between the plusoptiX R09 device and the monitor. Be sure the keyboard
and the mouse is switched on.
Make sure that any cables or connectors which show any damage are
replaced before switching on the plusoptiX R09 system.
Use only the delivered power adapter and the delivered cables.
The plusoptiX S09 complies with the requirements of the directive of medical devices
2007/47/EG.
1.5 Duties of the operator
The operator must ensure that only personnel who have been trained in handling of the
plusoptiX R09 are permitted to operate the system. All users must read the operating
manual and take note of the safety instructions and provisions.
Note:
Training courses on the operation of the plusoptiX R09 subject to safety notes
and provisions for medical products are available on request.
Do not connect systems other than those supplied by Plusoptix.
Page 5 of 34
