Digit Recognition (AI) Demo Design
camera is not pointing to a digit, the network will still output a digit that has the maximum value from the
fully connected layer.
4.5

Resource Utilization

The following table lists the resource utilization of the digit recognition demo design.
Table 2 • Resource Utilization
Type Used
4LUT 7203
DFF 7168
User I/O 37
(single-ended)
RAM1K18 20
MACC 20
Chip Globals 8
Microsemi Proprietary UG0891 Revision 1.0
Total Percentage
12084 59.61
12084 59.32
138 26.81
21 95.24
22 90.91
8 100
