SMC Networks PSE300A Series Manual page 2

Sensor Monitor
3-Screen Display
Improved Operability
Visualisation of Settings
The sub screen (label) shows the
item to be set.
Mode
Examples
Simple 3-Step Setting
When the S button is pressed and the
set value (P_ 1 ) is being displayed, the
set value (threshold value) can be set.
When the S button is pressed and the
hysteresis (H_ 1 ) is being displayed, the
hysteresis value can be set.
Now with a snap
shot function for
set value reading
Easy Screen Switching
It is possible to change the settings while checking the measured value.
Main screen
Measured value
(Current pressure value)
Sub screen/Left side
Label (Display item)
Sub screen/Right side
Set value (Threshold value)
1
PSE300A
PSE300A
Always
displayed on
one screen
Normal output
(Threshold value)
Hysteresis
mode
Normal output/
Window
Lo side (Threshold value)
comparator
mode
1
Push
Setting start
Push
Setting start
The sub screen can be switched by pressing the up/down buttons.
OUT1
Set value (Threshold value)
Series
PRESSURE
OUT1 OUT2
SET
Set value Set value
Reversed output
(Threshold value)
Set value Normal output/ Set value
Hi side (Threshold value)
2
Use the or
to adjust to the set value.
Pressing the and
simultaneously for a minimum of 1 second will
make the set value (threshold value) the same
as the current pressure value. as the current pre
Release the buttons after "---"
is displayed on the right side
sub screen.
OUT1 OUT2
Hysteresis value Set value (Threshold value) Hysteresis value
∗ One additional arbitrary display mode can be added via the function settings.
Existing model
PRESSURE
MPa
Switches
OUT1
between
displays
SET
Set hysteresis
Hysteresis
value
Reversed output/ Set value Reversed output/
Lo side (Threshold value) Hi side
3
Push
button
Setting completed
buttons
Push
Setting completed
OUT2
Bottom value
MPa
OUT2
Set value
(Threshold value)
Peak value
