SMC Networks PSE300A Series Manual

3-Screen Display
Compact Pneumatic
Pressure Sensor
PSE54
Compact Pneumatic
Pressure Sensor
PSE53
It is possible to change the settings while
checking the measured value.
Visualisation of Settings
Set value
(Threshold value)
Peak value
PSE300A
Sensor Monitor
Low Differential
Pressure Sensor
Compatible
with 5 types of
pressure sensor
Main screen
Measured value
(Current pressure value)
Sub screen
Left side Right side
Label Set value
(Display item) (Threshold value)
Hysteresis value
Bottom value
Series
PSE550 PSE550 0
NPN/PNP Switch Function
Selectable
NPN
Input Range Selection
¡ Set the displayed value according to the sensor
input.
(Voltage input: 1 to 5 V/Current input: 4 to 20 mA)
¡ Value is displayed regardless of the pressure
switch or fl ow switch.
New
New
RoHS
Pressure Sensor
for General Fluids
PSE57
Pressure Sensor
for General Fluids
PSE56
1 sensor
monitor for
2 output types
reduces
stock.
PNP
(for Pressure/Flow rate)
CAT.EUS100-126A-UK
®
