PSE300A

Function Details

Display examples of the main and sub (set value) screens of each mode.
Hysteresis mode, Normal output
Threshold value setting
Switch ON
Turns ON at the
set value or more.
Measured value
Switch OFF
0.0 0.1 0.2
Hysteresis mode, Reversed output
Threshold value setting
Measured value
Switch ON
Turns ON at the
set value or less.
Switch OFF
0.0 0.1 0.2
Window comparator mode, Normal output
Threshold value setting
Switch ON
Turns ON at the
set value or more.
Measured value
Switch OFF
0.0 0.1 0.2
Window comparator mode, Reversed output
Threshold value setting
Measured value
Switch ON
Turns ON at the
set value or less.
Switch OFF
0.0 0.1 0.2
Series
Measured value
0.3 0.4 0.5 0.6 0.7 MPa
Measured value
0.3 0.4 0.5 0.6 0.7 MPa
Turns ON at the
set value or less.
Measured
value
0.3 0.4 0.5 0.6 0.7 MPa
Turns ON at the
set value or more.
Measured
value
0.3 0.4 0.5 0.6 0.7 MPa
Hysteresis setting
Switch ON
Difference between
OFF ON and ON OFF
Switch OFF
0.40
Hysteresis setting
Switch ON
Difference between
ON OFF and OFF ON
Switch OFF
0.45
Hysteresis setting
Switch ON
Difference
between
ON and OFF
Switch OFF
0.2 0.3
Hysteresis setting
Switch ON
Difference
between
ON and OFF
Switch OFF
0.3 0.4
0.45 0.50 0.55 MPa
0.50 0.55 0.60 MPa
......... 0.6 0.7 MPa
......... 0.5 0.6 MPa
