PSE300A
Series
Function Details
Copy function (F97)
L
The settings of the master sensor can be copied to the slave
sensors, reducing setting labour and minimizing the risk of setting
mistakes.
The set value can be copied to up to 10 sensors simulta-
neously. (Maximum transmission distance: 4 m)
1 unit
Master
Master sensor
1 unit
Power supply
1) Wire as shown in the fi gure above.
2) Select the slave sensor which is to be the master, and change it
into a master using the buttons. (In the default setting, all sensors
are set as slaves.)
3) Press the button on the master sensor to start copying.
Analogue free span function (F5)
N
For the displayed value, the analogue span point (5 V, 20 mA) can
be changed within the rated pressure range of 10 to 105 % ∗
Analogue output
5 V
20 mA
At the time of
shipment
1 V
4 mA
0 % 10 %
∗1 Up to the upper limit of the display/set pressure range
13
2 units 10 units
Slaves (Max. 10 units)
Slave sensors
n units
(Max. 10 units)
2 units
Changeable range
100 % 105 %
The F in ( ) shows the function code number. Refer to the operation
manual for details on operation procedures and function codes.
Auto-shift function (F5)
M
When there are large fl uctuations in the supply pressure, the switch
may fail to operate correctly.
This function compensates for such supply pressure fl uctuations. It
measures the pressure at the time of auto-shift signal input and uses
it as the reference pressure to correct the set value on the switch.
Set value correction by auto-shift function
P - 1
(P - 2)
ON
Switch output
1·(2)
OFF
Hi
Auto-shift
input
Lo
When the auto-shift function is selected, "
on the sub screen for about 1 second, and the pressure value at that
point will be saved as reference value "
reference value, output on-off points controlled by set values ∗
as " ," " ," "
∗2
When an output is reversed, output on-off points displayed at "
" ," " ," and "
The above is an example in hysteresis mode. On-off points are
similarly rectified in window comparator mode. Outputs that
enable the auto-shift function can be changed via the settings.
Settable Range for Auto-Shift Input
Range settings
0 to 2 kPa
-101 to 0 kPa
1
.
-100 to 100 kPa
0 to 100 kPa
0 to 500 kPa
0 to 1 MPa
0 to 2 MPa
0 to 5 MPa
0 to 10 MPa
0 to 20 MPa
0 to 25 MPa
Display
Auto-shift zero
The basic function of auto-shift zero is the same as that of auto-
shift. However, it corrects values on the display based on a
pressure value of " ", which is set as the reference value when
auto-shift function is selected.
Supply pressure Supply pressure
normal drop
Rectified
H - 1
(H - 2)
A
5 ms or more 10 ms or less
∗1 When delay time is 1.5 ms or less
," and " " will also be rectifi ed.
" will be rectifi ed.
-2.30 to 2.300 kPa
-115.0 to 115.0 kPa
-210 to 210.0 kPa
-115.0 to 115.0 kPa
-575 to 575 kPa
-1.155 to 1.155 MPa
-2.20 to 2.205 MPa
-5.50 to 5.50 MPa
-11.00 to 11.00 MPa
-22.0 to 22.00 MPa
-27.5 to 27.52 MPa
Supply pressure
incrase
Rectified
B
Switch output
response time
when auto-
shift is input. ∗
1
" will be displayed
" Based on the saved
2 such
,"
Settable range
