SMC Networks PSE56 Series Operation Manual

Pressure sensor for general fluids
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
No.PS※※-OMG0006-D
PRODUCT NAME
Pressure Sensor for General Fluids
MODEL / Series / Product Number
PSE56#

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PSE56 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SMC Networks PSE56 Series

Summary of Contents for SMC Networks PSE56 Series

  • Page 1 No.PS※※-OMG0006-D PRODUCT NAME Pressure Sensor for General Fluids MODEL / Series / Product Number PSE56#...

  • Page 2: Table Of Contents

    Table of Contents Safety Instructions Model Identification and How to Order Definition and terminology Mounting and Installation Wiring Troubleshooting Specification Specifications Dimensions No.PS※※-OMG0006-D...

  • Page 3: Safety Instructions

    Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of "Caution", "Warning" or "Danger". They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC)*1), and other safety regulations.
  • Page 4 Safety Instructions Caution 1.The product is provided for use in manufacturing industries. The product herein described is basically provided for peaceful use in manufacturing industries. If considering using the product in other industries, consult SMC beforehand and exchange specifications or a contract if necessary. If anything is unclear, contact your nearest sales branch.
  • Page 5 Operator This operation manual is intended for those who have knowledge of machinery using pneumatic equipment, and have sufficient knowledge of assembly, operation and maintenance of such equipment. Only those persons are allowed to perform assembly, operation and maintenance. Read and understand this operation manual carefully before assembling, operating or providing maintenance to the product.
  • Page 6 Caution ■After maintenance is complete, perform appropriate functional inspections and leak tests. Stop operation if the equipment does not function properly or there is a leakage of fluid. When leakage occurs from parts other than the piping, the product might be faulty. Disconnect the power supply and stop the fluid supply.
  • Page 7 ●Product handling Installation Follow the specified tightening torque. Excessive tightening torque can break the Pressure Sensor. Insufficient tightening torque can displace the Pressure Sensor from the original position or loosen the mounting screws. Refer to the following table for the appropriate torque values. Nominal size screws Appropriate tightening torque (Nm) RNPTRc1/8...
  • Page 8 Keep wiring as short as possible to prevent interference from electromagnetic noise and surge voltage. Do not use a cable longer than 30 m. Wire the DC(-) line(blue) as close as possible to the power supply. When analogue output is used, install a noise filter (line noise filter, ferrite element, etc.) between the switch-mode power supply and this product.

  • Page 9: Model Identification And How To Order

    Model Indication and How to Order ○Option Description Part number Remarks Connector for pressure sensor controller ZS-28-C 1 pc. Adapter with throttle Rc1/4 ZS-31-X175 1 pc. Adapter with throttle NPT1/4 ZS-31-X186 1 pc. Adapter with throttle Rc1/8 ZS-31-X188 1 pc. Adapter with throttle NPT1/8 ZS-31-X189 1 pc.

  • Page 10: Mounting And Installation

    Mounting and Installation ■Wiring ○Attaching the connector to the lead wire Sensor wire is stripped as shown in the right figure. Do not cut the insulation. The core of the corresponding color shown in the following table is put into the pin of the number stamped on the connector for sensor connection to the back.
  • Page 11 ○Internal circuit and wiring example Output specification □-□ PSE56 Voltage output: 1 to 5 V Output impedance: Approx. 1 kΩ □-□ PSE56 Current output: 4 to 20 mA Allowable load impedance: 500 Ω or less (at 24 VDC) 100 Ω or less (at 12 VDC) : Install the load either on the LINE(+) or LINE(-) side.

  • Page 12: Troubleshooting

    Troubleshooting ○Cross-reference for troubleshooting Problem Possible cause Investigation method Countermeasure Check if the analogue output line is Incorrect wiring Correct the wiring. connected with a load. (1) Check if the proper load is connected. Non-compliance (2) Check if input impedance of input Connect a proper load.

  • Page 13: Specification

    Specification ■Specifications Model No. PSE560 PSE561 PSE563 PSE564 Rated pressure range 0 to 1 MPa 0 to -101 kPa -100 to 100 kPa 0 to 500 kPa Extension analogue output range -0.1 to 0 MPa 10.1 to 0 kPa -50 to 0 kPa Withstand pressure 1.5 MPa 500 kPa...
  • Page 14 ○Analogue output Range Rated pressure range For vacuum 0 to -101 kPa -101 kPa 10.1 kPa For compound -100 to 100 kPa -100 kPa 100 kPa 0 to 1 MPa 1 MPa -0.1 MPa For positive pressure 0 to 500 kPa 500 kPa -50 kPa -13-...

  • Page 15: Dimensions

    ■Dimensions PSE56□- , PSE56□- Be sure to release the air in the air tube of the cable to the atmosphere. If the air tube is restricted, or left in an environment where it is exposed to water or oil, it cannot be detected normally. PSE56□-C01 Model No.
  • Page 16 Revision history A: For B: Complete revision C: Contents revised in several places. D: Contents revised in several places. [July 2018] 4-14-1, Sotokanda, Chiyoda-ku, Tokyo 101-0021 JAPAN Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 http://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer.
