ORDERING INFORMATION

BILL OF MATERIALS

Table 5. Motherboard
Qty Reference Designator
12 C1, C4, C5, C8, C10, C12, C16,
C17, C21, C23, C25, C26
2 C6, C9
1 C7
8 C11, C13, C14, C15, C18, C19,
C20, C22
1 C24
10 D1, D2, D3, D4, D9, D10, D11,
D16, D17, D18
1 D5
7 D6, D7, D8, D12, D13,
D14, D15
3 D19, D20, D21
1 D22
2 D23, D24
10 R1, R5, R7, R9, R12, R14, R16,
R18, R20, R22
10
R2, R6, R8, R10, R13, R15, R17,
R19, R21, R23
1 R3
6 R4, R11, R31, R32, R34, R36
3 R24, R27, R29
3 R25, R26, R28
1 R35
2 R39, R40
1 R30
1 R33
2 R37, R38
1 U1
3 U2, U3, U4
1 U5
1 Y1
1 Q1
1 JP2
30 J1 to J28, J31, J32
1 J29
1 J30
2 J33, J34
5 LK1, LK2, LK3, LK4, JP1
1 S1
Description
100 nF, 10 V, 0402, X5R, MLCC capacitor
6.0 pF, 0402, NP0, MLCC capacitor
10 μF, 6.3 V, 0603, X5R, MLCC capacitor
2.2 μF, 10 V, 0603, X5R, MLCC capacitor
47 μF, 16 V, 1210 X5R, MLCC capacitor
Blue 0805, SMD, LED
Red, 0805, SMD LED
White, 0805, SMD LED
Green, 0805, SMD LED
Schottky diode, SC70
USB ESD protector
100 Ω, 1%, 0603, SMD, resistor
49.9 Ω, 1%, 0402, SMD resistor
220 Ω, 1%, 0603, SMD resistor
10 kΩ, 1%, 0603, SMD resistor
100 kΩ, 1%, 0402, SMD resistor
680 Ω, 1%, 0603, SMD resistor
31.6 kΩ, 1%, 0402, SMD resistor
4.75 Ω, 1%, 0603, SMD resistor
36.5 kΩ, 1%, 0603, SMD resistor
24.3 Ω, 1%, 0402, SMD resistor
2.21 kΩ, 1%, 0402, SMD resistor
IC MCU USB peripheral high SPD-56QFN
IC LDO regulator, 500 mA, 8-Lead MSOP
Microchip Serial EEPROM-64K, MSOP8
Crystal 24 MHz
MOSFET N-channel, SOT23
USB Connector USB Mini-B, 5-pin
0.100, single, STR, 2-pin header
0.100, single, STR, 4-pin header
0.100, dual, STR, 28-pin header
Male 0.100, dual, STR, 2 × 10 pin header
0.100, single, STR, 3-pin header
Push-button switch, SMD
Rev. 0 | Page 23 of 24
Manufacturer/Vendor
Murata Manufacturing Co., Ltd.
Vishay/Panasonic
Murata Manufacturing Co., Ltd.
Murata Manufacturing Co., Ltd.
Murata Manufacturing Co., Ltd.
Lumex Inc.
Lumex Inc.
Osram
Lumex Inc.
ON Semiconductor
Bourns
Vishay Dale or equivalent
Panasonic or equivalent
Vishay Dale or equivalent
Vishay Dale or equivalent
Vishay Dale or equivalent
Vishay Dale or equivalent
Vishay Dale or equivalent
Vishay Dale or equivalent
Vishay Dale or equivalent
Vishay Dale or equivalent
Vishay Dale or equivalent
Cypress Semiconductor Corp
Analog Devices, Inc.
Microchip
CTS Corporation
Fairchild
Delphi Corporation/Molex
Sullins Connector Solutions
Sullins Electronics, Inc.
Sullins Electronics, Inc.
Sullins Connector Solutions
Sullins Connector Solutions
C & K Components
EVAL-ADP8860
Part Number
GRM155R61A104KA01B
ECJ0EC1H060D
GRM188R60J106ME
GRM188R61A225K
GRM32ER61C476K
SML-LX0805USBC-TR
SML-LXT0805IW-TR
LW M67C-S1T2-5K8L-Z
SML-LXT0805GW-TR
MBR0530T1G
CG0603MLC-05E
CRCW0603100RFKE
ERJ-2RKF49R9X
CRCW0603220RFKE
CRCW040210022F
CRCW04021003F
CRCW04026810F
CRCW04023162F
CRCW06034R75FKTA
CRCW060336K5FKE
CRCW040224K3FKE
CRCW04022211FRT1
CY7C68013A
ADP1715/ADP1716
M24LC64 or 24AA64
CTX651CT
FDN335N
15430262-110
S1012-36-ND
PEC36SAAN
PEC14DAAN
PTC10SAAN
PEC03SAAN
KSC321JLFS
