EVAL-ADP8860
Table 4. Daughterboard
Qty Reference Designator
3 C1, C2, C5
1 C3
3 C4, C6, C7
4 R1, R2, R3, R4
2 D2, D3
1 U1
2 J1, J2
5 LK2, LK3, LK4, LK5, LK6
2 JP5, JP6

ORDERING GUIDE

Model Description
1
ADP886XADAPT-EVALZ Motherboard
1
ADP8860DBCP-EVALZ Daughterboard—LFCSP Version
1
ADP8860DBCB-EVALZ Daughterboard—WLCSP Version
1
Z = RoHS Compliant Part.
©2009 Analog Devices, Inc. All rights reserved. Trademarks and
registered trademarks are the property of their respective owners.
Description
1 μF, 10 V, 0603, X5R, MLCC capacitor
10 μF, 6.3 V, 0603, X5R, MLCC capacitor
100 nF, 10 V, 0402, X5R, MLCC capacitor
10 kΩ, 1%, 0402 resistor
6-pin chiplead phototransistor
20-ball, WLCSP ADP8860
0.100, double-row 10-pin header
0.100, single, STR, 2-pin header
0.100, single, STR, 3-pin header
EB07988-0-7/09(0)
Rev. 0 | Page 24 of 24
Manufacturer/Vendor
Taiyo Yuden
Taiyo Yuden
Murata Manufacturing Co., Ltd.
Vishay Dale
Avago
Analog Devices
SAMTEC
Sullins Electronics, Inc./3M
Sullins Electronics, Inc./3M

ESD CAUTION

Part Number
LMK107BJ105KK-T
JMK107BJ106MA
GRM155R61A104KA01B
CRCW04021002F
APDS-9005-020
ADP8860ACBZ-R7
SSW-110-03-G-D
S1012-36-ND
S1012-36-ND
