Tektronix 1S1 Instruction Manual page 141

Parts List – Type 1S1
Tektronix
Ckt. No.
Part No.
R107 321-0222-00
R109 321-0170-00
R110 311-0480-00
R111 323-0353-00
R114 308-0258-00
R115 301-0472-00
R118 323-0353-00
R120 321-0339-00
R124 304-0104-00
R126 315-0101-00
R128 315-0563-00
R130 308-0313-00
R133 315-0101-00
R139 321-0685-00
R140 321-0684-00
R145A 321-0665-00
R145B 321-0683-00
R145C 321-0682-00
R145D 321-0677-00
R145E 321-0675-00
R145F 321-0669-00
R145G 321-0666-00
R145H 321-0663-00
R145K 321-0680-00
R145L 321-0674-00
R145N 321-0707-00
R145P 321-0706-00
R153 303-0433-00
R157 315-0201-00
R159† 311-0529-00
R165 *311-0538-00
R167 301-0563-00
R168 311-0329-00
R170 321-0215-00
R172 311-0449-00
R174 321-0286-00
R175 315-0302-00
R177 321-0328-00
R180 323-0382-00
R183 301-0303-00
R185 315-0304-00
R190 321-0434-00
R192†† 311-0529-00
R193 321-0392-00
R194 311-0510-00
†Furnished as a unit with R192.
††Furnished as a unit with R159.
6-18
Resistors (Cont'd)
Description
2 k w
576 w
500
46.4 k ½ w
6 k 3 w
4.7 k ½ w
46.4 k ½ w
33.2 k w
100 k 1 w
100 ¼ w
56 k ¼ w
20 k 3 w
100 ¼ w
30 k w
15 k w
2.16 k w
182.5 k w
60.83 k w
30.4 k w
18.25 k w
6.08 k w
3.04 k w
1.07 k w
35.3 k w
17.4 k w
16.5 k w
25.5 k w
43 k 1 w
200 ¼ w
2.5 k
7 k
56 k ½ w
50 k
1.69 k w
1.5 k
9.31 k w
3 k ¼ w
25.5 k w
93.1 k ½ w
30 k ½ w
300 k ¼ w
324 k w
2.5 k
118k w
10 k
Prec
Prec
Var
Prec
WW
Prec
Prec
WW
Prec
Prec
Prec
Prec
Prec
Prec
Prec
Prec
Prec
Prec
Prec
Prec
Prec
Prec
Var
Var
Var
Prec
Var
Prec
Prec
Prec
Prec
Var
Prec
Var
S/N Range
1%
1%
Memory Bal
1%
5%
5%
1%
10%
5%
5%
1%
5%
½%
½%
½%
½%
½%
½%
½%
½%
½%
½%
½%
½%
½%
½%
5%
5%
DC OFFSET +/-1 V
VARIABLE (mVolts/CM)
5%
VAR BAL
1%
VERT GAIN
1 %
5%
1%
1%
5%
5%
1%
VERT POSITION
1%
Position Range
