Tektronix 1S1 Instruction Manual page 132

REF.
PART NO.
NO.
82 119-0054-00
- - - - - -
83 131-0007-00
84 136-0125-00
85 210-0006-00
86 344-0108-00
87 200-0365-00
88 358-0088-00
89 380-0035-00
90 132-0001-00
91 132-0007-00
92 131-0209-00
93 132-0208-00
94 132-0029-00
95 132-0002-00
96 - - - - - -
210-0006-00
210-0561-00
97 179-0981-00
98 179-0982-00
99 200-0263-00
EXPLODED VIEW (Cont'd)
SERIAL/MODEL NO.
EFF. DISC.
100 149X
X740
Q
T
Y.
ASSEMBLY, DELAY LINE
1 Assembly includes
-
1 CONNECTOR, cable end
2 SCREW, 6-32 x 5/16 inch BHS
2 LOCKWASHER, internal, #6
1 LUG, solder
1 COVER
1 BUSHING
1 HOUSING
1 NUT, coupling
1 SNAP, ring
1 CONNECTOR, inner conductor
1 INSULATOR
1 CONDUCTOR, inner
1 CONDUCTOR, sleeve, outer
- mounting hardware: (not included w/assembly)
1 LOCKWASHER
2 NUT, 6-32 x 3/16 inch
1 CABLE HARNESS, vertical
1 CABLE HARNESS, horizontal
1 COVER, dust
Parts List – Type 1S1
DESCRIPTION
6-9
