Tektronix 1S1 Instruction Manual page 139

Parts List – Type 1S1
Tektronix
Ckt. No.
Part No.
Q374 *151-0151 -00
Q384 *151-0133-00
Q424 * 151 -0142-00
Q454 *151-0103-00
Q464 *151-0134-00
Q485 151-0162-00
Q495 151 -0151 -00
Q614 *151-0151 -00
Q624 *151-0134-00
Q627 *151-0148-00
Q634 151 -0151 -00
Q653 *151-0136-00
Q657 *151-0148-00
Q667 Use 151-0150-00
Resistors are fixed, composition, ±10%, unless otherwise indicated.
R1 *308-0224-00
R4 317-0047-00
R5 317-0150-00
R7 321-0636-00
R8 321-0636-00
R13 315-0512-00
R14 315-0223-00
R16 323-0490-00
R17 323-0474-00
R19 321-0305-00
R21 315-0512-00
R22 311-0497-00
R24 323-0469-00
R25 323-0498-00
R27 321-0305-00
R30 311-0510-00
R32 321-0324-00
R33 321-0452-00
R34 321-0381-00
R36 317-0200-00
R38 308-0291-00
R39 321-0122-00
R42 321-0374-00
R44 308-0310-00
R47 323-0404-00
6-16
Transistors (Cont'd)
Description
Replaceable by 2N930
Selected from 2N3251
Selected from 2N3546
Replaceable by 2N2219
Replaceable by 2N2905
2N3324
Replaceable by 2N930
Replaceable by 2N930
Replaceable by 2N2905
Selected (RCA 40250)
Replaceable by 2N930
Replaceable by 2N3053
Selected (RCA 40250)
2N3440
Resistors
2.45 k ½w
4.7 w
15 w
100 w
100 w
5.1 k ¼w
22 k ¼w
1.24 meg ½w
845 k ½w
14.7 k w
5.1 k ¼w
50 k
750 k ½w
1.5 meg ½w
14.7 k w
10k
23.2 k w
499 k w
90.9 k w
20 w
2 k 3w
182 w
76.8 k w
12 k 5w
158 k ½w
WW 1%
5%
5%
Prec ½%
Prec ½%
5%
5%
Prec 1%
Prec 1%
Prec 1%
5%
Var Bridge Volts
Prec 1%
Prec 1%
Prec 1%
Var Bridge Bal
Prec 1%
Prec 1%
Prec 1%
5%
WW 5%
Prec 1%
Prec 1%
WW 1%
Prec 1%
S/N Range
