Tektronix 1S1 Instruction Manual page 130

REF.
PART NO.
NO.
56 210-0201-00
- - - - - -
213-0044-00
57 - - - - - -
- - - - - -
210-0940-00
210-0583-00
58 - - - - - -
- - - - - -
211-0021-00
210-0004-00
210-0406-00
59 - - - - - -
- - - - - -
386-0254-00
211-0597-00
60 670-0078-00
- - - - - -
388-0640-00
61 131-0391-00
62 136-0061-00
63 136-0183-00
64 343-0088-00
65 344-0108-00
66 352-0017-00
- - - - - -
361-0007-00
67 384-0519-00
- - - - - -
211-0504-00
210-0802-00
68 426-0121-00
- - - - - -
361-0007-00
69 - - - - - -
211-0504-00
211-0601-00
211-0055-00
211-0802-00
EXPLODED VIEW (Cont'd)
SERIAL/MODEL NO.
EFF. DISC.
X360
100 509
510
Q
T
Y.
3 LUG, solder
- mounting hardware for each: (not included w/lug)
1 SCREW, thread cutting, 5-32 x 3/16, inch, PHS phillips
1 POT
- mounting hardware: (not included w/pot)
1 WASHER, ¼ ID x inch OD
1 NUT, hex, ¼-32 x 5/16 inch
1 TRANSFORMER
- mounting hardware: (not included w/transformer)
2 SCREW, 4-40 x 1¼ inches, RHS
2 LOCKWASHER, internal, #4
2 NUT, hex, 4-40 x 3/16 inch
1 CAPACITOR
- mounting hardware: (not included w/capacitor)
1 PLATE, fiber, large
2 SCREW, 6-32 x ¼ inch, RHS phillips
1 ASSEMBLY, board, (VERTICAL) (See Ref. #69)
- assembly includes:
1 BOARD, etched circuit
2 CONNECTOR, male
2 SOCKET, 9 pin
8 SOCKET, transistor, 3 pin
1 CLAMP, cable
14 CLAMP, diode
1 HOLDER, nylon
- mounting hardware: (not included w/holder alone)
1 SPACER, nylon
2 ROD, spacing
- mounting hardware for each: (not included w/rod alo
1 SCREW, 6-32 x ¼ inch, BHS
2 WASHER, 6s x 5/16 inch
5 MOUNT, toroid
- mounting hardware: (not included w/mount alone)
1 SPACER, nylon
1 mounting hardware: (not included w/assembly)
6 SCREW, 6-32 x ¼ inch, BHS
6 SCREW, sems, 6-32 x 5/16 inch, PHB, phillips
6 LOCKWASHER, #6 split
6 WASHER, 6S x 5/16 inch
Parts List – Type 1S1
DESCRIPTION
6-7
