Tektronix 1S1 Instruction Manual page 134

Values are fixed unless marked variable.
Tektronix
Ckt. No. Part No.
Tolerance ±20% unless otherwise indicated.
}
C4
*283-0123-00
C5
}
C4
*283-0124-00
C5
C33 281-0578-00
C36 281-0538-00
C37 281-0538-00
C39 283-0059-00
C42 283-0079-00
C49 283-0059-00
C54 283-0059-00
C56 283-0065-00
C66 283-0059-00
C68 283-0092-00
C74 283-0026-00
C76 283-0594-00
C80 283-0067-00
C81 281-0523-00
C82 283-0067-00
C83 283-0059-00
C84 281-0573-00
C85 283-0067-00
C86 283-0079-00
C87 281-0503-00
C88 283-0069-00
C89 283-0069-00
C93 283-0026-00
C101 283-0026-00
C110 283-0051-00
C115 283-0067-00
C122 281-0504-00
C133 283-0026-00
C135 281-0022-00
C136 283-0618-00
C145 283-0067-00
C157 283-0079-00
C192 283-0079-00
C205 283-0077-00
C210 285-0598-00
C220 283-0060-00
C228 283-0000-00
C232 283-0004-00
Description
Capacitors
Assembly Cer
Assembly Cer
18 pf Cer
1 pf Cer
1 pf Cer
1 uf Cer
0.01 uf Cer
1 uf Cer
1 uf Cer
0.001 uf Cer
1 uf Cer
0.03 uf Cer
0.2 uf Cer
0.001 uf Mica
0.001 uf Cer
100 pf Cer
0.001 uf Cer
1 uf Cer
11 pf Cer
0.001 uf Cer
0.01 uf Cer
8 pf Cer
15 pf Cer
15 pf Cer
0.2 uf Cer
0.2 uf Cer
0.0033 uf Cer
0.001 uf Cer
10 pf Cer
0.2 uf Cer
8-50 pf Cer
130 pf Mica
0.001 uf Cer
0.01 uf Cer
0.01 uf Cer
330 pf Cer
0.01 uf PTM
100 pf Cer
0.001 uf Cer
0.02 uf Cer
500 v
500 v
500 v
25 v
250 v
25 v
25 v
100 V
25 v
200 v
25 v
100 V
200 v
350 v
200 v
25 v
200 v
250 v
500 v
50 V
50 v
25 v
25 v
100 V
200 v
500 v
25 v
Var
300 v
200 v
250 v
250 v
500 v
100 v
200 v
500 v
150 v
Parts List – Type 1S1
S/N Range
100-149
150-up
5%
5%
1%
10%
10%
10%
10%
±.5 pf
5%
10%
10%
2%
10%
5%
5%
5%
6-11
