Tektronix 1S1 Instruction Manual page 128

REF.
PART NO.
NO.
28 - - - - - -
210-0586-00
210-0579-00
210-0049-00
29 384-0631-00
- - - - - -
212-0046-00
30 366-0125-00
- - - - - -
213-0004-00
31 384-0510-00
- - - - - -
32 354-0025-00
33 210-0894-00
34 337-0743-00
- - - - - -
211-0504-00
35 333-0873-00
36 131-0017-00
- - - - - -
211-0004-00
210-0586-00
37 348-0031-00
38 131-0206-00
- - - - - -
210-0260-00
210-0559-00
39 136-0140-00
- - - - - -
210-0223-00
210-0465-00
40 136-0140-00
- - - - - -
210-0895-00
210-0223-00
210-0465-00
41 200-0293-00
42 260-0689-00
- - - - - -
210-0046-00
210-0940-00
210-0583-00
EXPLODED VIEW (Cont'd)
SERIAL/MODEL NO.
EFF. DISC.
Q
DESCRIPTION
T
Y.
- mounting hardware: (not included w/switch)
2 NUT, keps, 4-40 x ¼ inch
1 NUT, hex, 5/8-24 x ¾ inch
1 LOCKWASHER, internal, 5/8 inch ID
4 ROD, frame
- mounting hardware for each: (not included w/rod)
1 SCREW, 8-32x inch, THS phillips
1 KNOB, plug-in securing
- knob includes:
1 SCREW, set, 6-32 x 3/16 inch, HSS
1 ROD, securing
- rod includes:
1 RING, retaining
1 WASHER, polyethylene, .567 OD x .033 inch ID
1 SHIELD
- mounting hardware: (not included w/shield)
1 SCREW, 6-32 x ¼ inch, BHS
1 PANEL, front
1 CONNECTOR, 16 contact
- mounting hardware: (not included w/connector)
2 SCREW, 4-40 x ¼ inch, BHS
2 NUT, keps, 4-40 x ¼ inch
3 CONNECTOR, coax, w/nut
mounting hardware: (not included w/connector)
LUG, solder, inch
1 CONNECTOR, probe power
- mounting hardware: (not included w/connector)
1 LUG, solder
1 NUT, hex, 7/16-28 x 9/16 inch
2 SOCKET, banana jack
- mounting hardware for each: (not included w/socket)
1 LUG, solder
1 NUT, hex, ¼-32x inch
4 SOCKET, banana jack
- mounting hardware for each: (not included w/socket)
1 WASHER, insulating
1 LUG, solder
2 NUT, hex, ¼-32 x inch
COVER, capacitor, polyethylene, 2 9/16x1.365 inch ID
1 SWITCH, unwired-START
- mounting hardware: (not included w/switch)
1 LOCKWASHER, .400 OD x.261 inch ID
1 WASHER, ¼ ID x inch OD
2 NUT, hex, ¼-32 x 5/16 inch
Parts List – Type 1S1
6-5
