Parts Ordering Information; Abbreviations And Symbols; Special Notes And Symbols - Tektronix 1S1 Instruction Manual

Replacement parts are available from or through your local Tektronix Field Office.
Changes to Tektronix instruments are sometimes made to accommodate improved
components as they become available, and to give you the benefit of the latest circuit
improvements developed in our engineering department. It is therefore important, when
ordering parts, to include the following information in your order: Part number including
any suffix, instrument type, serial number, and modification number if applicable.
If a part you have ordered has been replaced with a new or improved part, your
local Tektronix Field Office will contact you concerning any change in part number.
a or amp amperes
BHS binding head steel
C carbon
cer ceramic
cm centimeter
comp composition
cps cycles per second
crt cathode-ray tube
CSK counter sunk
dia diameter
div division
EMC electrolytic, metal cased
EMT electroyltic, metal tubular
ext external
f farad
F & I focus and intensity
FHS flat head steel
Fil HS fillister head steel
g or G giga, or 10
Ge germanium
GMV guaranteed minimum value
h henry
hex hexagonal
HHS hex head steel
HSS hex socket steel
HV high voltage
ID inside diameter
incd incandescent
int internal
k or K kilohms or kilo (10
kc kilocycle
m milli, or 10
mc megacycle
X000
000X
*000-000
Use 000-000

PARTS ORDERING INFORMATION

ABBREVIATIONS AND SYMBOLS

9
3
)
-3

SPECIAL NOTES AND SYMBOLS

Part first added at this serial number.
Part removed after this serial number.
Asterisk preceding Tektronix Part Number indicates manufactured by or for Tektronix,
or reworked or checked components.
Part number indicated is direct replacement.
Internal screwdriver adjustment.
Front-panel adjustment or connector.
mm millimeter
meg or M megohms or mega (10
met. metal
µ micro, or 10
n nano, or 10
a ohm
OD outside diameter
OHS oval head steel
p pico, or 10
PHS pan head steel
piv peak inverse voltage
pIstc plastic
PMC paper, metal cased
poly polystyrene
Prec precision
PT paper tubular
PTM paper or plastic, tubular, molded
RHS round head steel
rms root mean square
sec second
Si silicon
S/N serial number
t or T tera, or 10
TD toroid
THS truss head steel
tub. tubular
v or V volt
Var variable
w watt
w/ with
w/o without
WW wire-wound
6
)
-6
-9
-12
12
6-1
