Tektronix 1S1 Instruction Manual page 131

Parts List – Type 1S1
REF.
PART NO.
NO.
70 670-0079-00
- - - - - -
388-0639-00
71 131-0391-00
72 136-0125-00
387-0603-00
73 136-0183-00
74 344-0108-00
- - - - - -
211-0504-00
211-0601-00
210-0055-00
210-0802-00
75 670-0080-00
- - - - - -
388-0638-00
76 136-0183-00
77 344-0108-00
- - - - - -
211-0504-00
211-0511-00
210-0055-00
210-0802-00
78 385-0184-00
- - - - - -
211-0507-00
79 380-0073-00
80 337-0151-00
81 386-0151-00
- - - - - -
211-0507-00
6-8
EXPLODED VIEW (Cont'd)
SERIAL/MODEL NO.
EFF. DISC.
100 359X
100 509
510
100 449
450
Q
T
Y.
1 ASSEMBLY, board (HORIZONTAL)
- assembly includes:
1 BOARD, etched circuit
2 CONNECTOR, male
1 SOCKET, 5 pin
1 PLATE, insulating
18 SOCKET, transistor, 3 pin
2 CLIP, diode
- mounting hardware: (not included w/assembly)
8 SCREW, 6-32 x ¼ inch, BHS
8 SCREW, sems, 6-32 x 5/16 inch, PHB, phillips
8 LOCKWASHER, #6 split
8 WASHER, 6S x 5/16 inch
1 ASSEMBLY, board (REGULATOR)
- assembly includes:
1 BOARD, etched circuit
3 SOCKET, transistor, 3 pin
2 CLIP, diode
- mounting hardware: (not included w/assembly)
4 SCREW, 6-32 x ¼ inch, BHS
4 SCREW, 6-32 x ½ inch, PHS, phillips
4 LOCKWASHER, #6 split
4 WASHER, 6S x 5/16 inch
4 ROD, spacer
- mounting hardware for each: (not included w/rod)
1 SCREW, 6-32 x 5/16 inch, BHS
1 HOUSING, delay line
1 SHIELD, delay line
1 PLATE, delay line
- mounting hardware: (not included w/plate)
4 SCREW, 6-32 x 5/16 inch, BHS
DESCRIPTION
